Laser level LL500, the time-tested workhorse.

The Laser level LL500 is a one-person leveling system designed for longer range measurements across your entire site. Accurate, stable and reliable, the LL500 features a 1,650 ft (500 m) working diameter which increases productivity by reducing the need for multiple setups on a large job site.

SKU: LL500 Categories: Building Construction, Laser Levels, Receivers, Detectors, & Accessories, Spectra Precision

Spectra Precision LL500 Laser Level

Spectra Precision LL500 Laser Level - Image 2

Spectra Precision LL500 Laser Level - Image 3

Description
Additional information
Downloads

Spectra Precision LL500 Laser Level

Features & Benefits:

Temperature Compensation - provides highly stable, repeatable accuracy even under large temperature changes.

One Person Elevation Control - with 1,650 ft (500 m) diameter range increases productivity.

Maintains Performance - Maintains performance, even in harsh job site conditions.

Proven Workhorse - Trusted Over 40 years.

Self-leveling - with built-in shut off for increased accuracy over the entire work area and reduced errors.

Accuracy and Range - Ideally suited for high-accuracy job sites, including concrete work.

Specifications:

Self-Leveling Range
±11 arc minutes

Compensation Type
Wire Hung, Air Damped

Accuracy
1.5 mm at 30 m (1/16 in at 100 ft)

Laser Type
670nm visible, Class 2

Battery Life 20°C (68°F)
4 D-Cell Alkaline - 175 hrs NiMH - 100 hrs.

Operating Diameter
500m (1,600ft)

Operating Temperature
-20°C to 50°C (-4°F to 122°F)

Weight
3.6 kg (8 lbs)

Tripod Mount
5/8 in x 11

Warranty
5 Years

Additional information

Weight	20 lbs

Spectra Precision LL500 Laser Level Data Sheet

Spectra Precision LL500 Laser Level User Guide
