Trimble SPS720252210 Robotic Total Station

Trimble SPS720252210 Robotic Total Station

Trimble Site Positioning Systems Total Stations are packed with market leading features such as:

• Long life integrated batteries for a full day of uninterrupted work
• Choice of Trimble controllers or tablets to suit your site needs
• Intuitive Trimble Siteworks Site Positioning Systems Software

Well suited for use on:

• Smaller construction sites or combined with GNSS on larger sites
• Tasks where the accuracy requirements are tight
• Measuring dangerous or inaccessible locations

No matter what job you are doing, Trimble robotic total stations will deliver unmatched user experience, all-around capability and incredible results, priced for a quick return on investment.

Key Features:

Trimble DR Plus Long-Range Reflectorless Measurement
The Trimble DR Plus™ long-range reflectorless measurement capability allows you to measure hard-to reach or unsafe places up to 2 kilometers (1.2 miles) away. There is no need to walk the surface with a target, so you’ll increase productivity and safety when measuring stockpiles, or profiling cuttings and rock faces.

Internal Radio
Trimble Robotic Total Stations are equipped with an internal radio that operates in the public free 2.4 GHz band. The radio uses frequency hopping technology to reduce radio interference and maintain radio communications in even the harshest radio frequency (RF) environments.

Automatic Functions
Take accurate measurements in less time, and get real-time alerts to make adjustments. Trimble Robotic Total Stations automatically correct for mislevelments +/- 6’, immediately warn the operator of any mislevelments beyond 6’ and average angles during distance measurements to increase consistency, prevent costly delays and subsequent rework. When measuring in standard mode, the Trimble SPSx20 Total Station takes approximately 2 seconds to measure the distance. Angles returned to the Trimble SPSx20 Total Station at 1000Hz are averaged over the 2 second period to obtain an average angle measurement; the resultant angle measurement is an average of over 2000 observations. More accurate data captured using a faster instrument speed means increased productivity and faster results to grade.

• Robotic and reflectorless features satisfy most site positioning needs.
• Active target function guarantees reliable lock on the correct target.
• DR Plus long-range reflectorless measurements eliminate the risk and delay of walking the surface with a target.
• Trimble MagDrive servos provide unmatched instrument turning and tracking speeds.
